Bo'ness Junction [1st]

Location type

Junction

Names and dates

Bo'ness High Junction (1851-1933)
Bo'ness Junction [1st] (1933-1979)

Note: text in square brackets is added for clarity and was not part of the location's name.

Opened on the Slamannan and Borrowstounness Railway.
Opened on the Edinburgh and Glasgow Railway.

Description

This junction gave the Edinburgh and Glasgow Railway access to the Bo'ness branch (Slamannan and Borrowstounness Railway). Approach was from the west. Both lines were doubled with the branch dropping to single track after Bo'ness Low Junction. This layout dated from 1893 when a signal box (^Manuel High Level^) opened here. The original 1851 connection was not direct but by reversal, with a very similar layout to today^s reversing spur and trailing connection to the E&G.

The first signal box was on the north side of the line on the east side of the road bridge directly west of the junction.

In 1933, when the Causewayend Junction to Bo'ness Low Junction section formally closed, the signal box was replaced. The new box was in the ^V^ of the junction between the E&G and the Bo^ness branch. This box also controlled the approach from Almond Junction (the far end of the Slamannan Junction Railway). It also replaced the box at Manuel High Level. The new box was called ^Bo^ness Junction^.

The stub of the Almond line, to Manuel Brick Factory, closed in 1972. The Bo^ness branch closed in 1979 and the box closed, control of the E&G here passing to the box at Polmont.

Note that through running from Bo^ness to the junction and on to Causewayend was not possible, the two junctions were out of alignment with the Bo^ness connection being west of the Causewayend connection.

Tags

Junction

Aliases

Boness High Junction

External links

NLS Collection OS map of 1892-1914
NLS Collection OS map of 1944-67
NLS Map
04/08/2020
